Hastek Fixing Support Systems |
PT. Hastek Indoraya Cipta has specialized in the design and supply of seismic bracing for plumbing, HVAC, mechanical systems, and machinery, and is proud to represent industry leader UTT Seismic Bracing lines. |
Designed for bracing pipes againts sway and seismic disturbance.
We offer Model UTT10 Ul/Fm approved Building Connection Attachment fitting. Our products have high standards of quality and durability. By providing safe and long-lasting plumbing solutions to our customers, we provide protection against earthquake risk.
Product description
Clevis Hanger Pipe
Material: Carbon steel
Finished Electro Plating
UL/FM Standard
Available size 1/2 to 12 inch
Use for suspending non-insulated stationary pipe, also stainless steel pipe, allowing for vertical adjustment
Model UTT20 Seismic Pipe Hanger Fitting complies with UL/Fm standards. Our products have high standards of quality and durability. By providing safe and long-lasting plumbing solutions to our customers, we provide protection against earthquake risk.
Rail Beam Clamp
Suit for channel 41*21mm, 41*41mm, 41*62mm, 41*82mm with slotted or plain
Low carbon steel, Stainless Steel3 04
Standard DIN/ISO/JIS/GB/ANSI/ASME/BSW, Class CL.4/6/8/10
Pipe Spiral Duct Clamp
Used for suspension of rigid circular ducts.
Dia 80 up to 400mm with screw M6 on either side, 1-point suspension with
M8/M10 nut on top.
Dia 450 up to 800mm with 2-point suspension with M10 hole on either side.
It ensures fast assembly thanks to an easy system of locking and tightening.
Version with a gasket prevents the transmission of vibrations from the
system to the building`s structure.
Products size
41*21mm, 41*41mm, 41*62mm, 41*82mm with slotted or plain with standard AISI, ASTM, GB, BS, EN, JIS, DIN or customer`s drawings
Product Material and Surface
Material: Carbon Steel
Surface coating: Pre-Galvanized, Hot For example
Corrosion Rating of Galvanized
Heated buildings with a clean atmosphere, such as offices, schools and hotels.
Galvanization wear: 0,0 μm - 0,1 μm in a year
Outdoor: Atmospheres with low contamination levels. Mostly rural areas.
Indoor: Unheated buildings with possible condensation, such as warehouses and sports halls.
Galvanization wear：0,1 μm - 0,7 μm in a year Dipped Galvanizing, Electrolytic Galvanizing
